by Keystone
Keystone KT-ALED140PS-M2-OSB-SF-8CSB-VDIM-P Slip Fitter Mount LED Area Light with Optic Swap, Power & CCT Selectable
SKU KT-ALED140PS-M2-OSB-SF-8CSB-VDIM-P
Original price
$0.00
-
Original price
$0.00
Original price
$352.43
$352.43
-
$352.43
Current price
$352.43
Availability:
in stock, ready to be shipped
Estimated Shipping Widget will be displayed here! (with custom color)
OVERVIEW
140W Power Select Color Select LED Area Light with NEMA Type 7-pin Twist Lock Receptacle + Shorting Cap. Series 2 Medium Housing. Optics Selectable B (Type III, IV, and V). Slip Fitter Mount. NEMA Type 3-pin Twist Lock Photocell. 120-277V Input. 0-10V Dim.
Features
- Finish: Bronze
- Wattage: 70W / 100W / 140W
- Voltage: 120-277V
- Color Temperature: 3000K / 4000K / 5000K Selectable
- Lumen: 9310 - 20780 depands on Power & CCT Selected
- CRI: 80+
- 0-10V Dimming
- Distribution Pattern: Type III Installed, Types IV and V Included
- Innovative optic swap capability under door frame and latch design for quick, tool-free lens change
- Heavy-duty, die-cast aluminum housing with ample heat sinkingLow-profile design delivers high-performance illumination and improves application site aesthetics
- Integrated NEMA/ANSI C136.10 7-pin twist-lock receptacle with 3-pin photocell and shorting cap
- Comes with a pre-installed slipfitter mount kit for quick and easy mounting to 2.38" tenons
Dimensions
- Length: 15.7"
- Width: 11.18"
- Height: 2.89"
Warranty
- 10 year limited warranty
Documents
Labels:
